FESLEY FED200 - Plug in the striking part connection cable

INSTALLATION GUIDE
7
06
Plug in the striking part connection cable
Hi-hat
Crash
Ride
●Please insert the connection cable in place to avoid poor contact and insert it correctly as
shown in the diagram.
Mode A: mechanical
Please check the drum for sound,If there is
no sound, please turn the switch,
Switch in A: mechanical kick drum mode,
Switch in B: pedal mode.
Mode B: pedal
*This product adopts mode B
kick drum
Drun Module
Tom1
Tom2
Tom3
Snare
Hi-hat Control
Kick drum pedal
