2 Technical Specifications
Festo CDPX-… en 1203NH
2-2
Electromagnetic Compatibility (EMC)
Radiated disturbance test Class A EN 55011
Radiated, radio-frequency,
electromagnetic field immunity test
80 MHz - 1 GHz, 10 V/m
1,4 GHz – 2 GHz, 3 V/m
2 GHz – 2.7 GHz, 1V/m
EN 61000-4-3
Immunity to conducted disturbances
inducted by radiofrequency field
0.15 - 80 MHz, 10 V EN 61000-4-6
Burst immunity test ±2 KV DC power port
±1 KV signal lines
EN 61000-4-4
Surge immunity test ±0,5 KV DC power port (line to earth)
±0,5 KV DC power port (line to line)
±1 KV signal lines (line to earth)
EN 61000-4-5
Electrostatic discharge immunity test 8 KV in air
4 KV in contact
EN 61000-4-2
Voltage dips, short interruptions and
voltage variations immunity test
Port: AC mains; Level:
100% duration: 1cycle and 250 cycles
(50Hz);
40% duration: 10 cycles (50Hz)
70% duration: 25 cycles (50Hz)
Phase: 0°-180°
EN61000-4-11
Interfaces
− Serial port
RS-232, RS-485, RS-422, software configurable 9-pin sub-D
coupling
