2 Technical Specifications
2-1 Festo CDPX-... en 1203NH
2 Technical Specifications
Power supply
Power supply voltage 18 … 30 V DC
Power consumption
(1)
Back-up battery
(1)
3 V 50mAh Lithium, rechargeable,
not user-replaceable, PANASONIC model VL2330
Fuse automatic
Touch screen technology Resistive
Notes:
1) Feature depends on the panel models; see Table below.
Environmental conditions
Operating temperature 0 - +50 C EN 60068-2-14
Storage temperature -20 - +70 C EN 60068-2-14
Operating and storage humidity 5 - 85%RH non-condensing EN 60068-2-30
Vibration 5 - 9 Hz, 7 mm peak-peak
9 - 150 Hz, 1 G
EN 60068-2-6
Shock 50 g, 11 ms, 3 pulses per axis EN 60068-2-27
Protection class Front IP66
(2)
Rear IP20
EN 60529
Notes:
2) The front face of the CDPX unit, installed in a solid panel, has been tested using
conditions equivalent to the standards shown in the “Environmental conditions”.
Even though the level of resistance CDPX unit is equivalent to these standards,
oils that should have no effect on the CDPX can possibly harm the unit. This can
occur in areas where either vaporized oils are present, or where low viscosity
cutting oil are allowed to adhere to the unit for long periods of time. If the front
face protection sheet on the CDPX becomes peeled off, these conditions can lead
to the ingress of oil into the CDPX and separate protection measures are
suggested.
If the installation gasket is used for a long period of time, or if the unit and its
gasket are removed from the panel, the original level of the protection cannot be
guaranteed.
