4 Getting Started
Festo CDPX-… en 1203NH 4-5
4.2 Dedicated LED Indicators
The table below shows the name and the symbol (if available)
of the LEDs dedicated to special functions.
( = on; = LED flashes)
LED Status Meaning
Name/symbol Colour
not marked
(above left)
Red Hardware fault
Battery low or
alarm requires acknowledgment
Green Normal operation
Communication error
Fig 4/1: Dedicated LED indicators
