Festo CP−FB6−E 0802f English 25
Type CP FB6−E
Pin 1
Operating voltage connection for
electronics (eletronics/inputs)
 Rated value
 Tolerance
 Current consumption of the
CP−FB6−E
 Current consumption of the complete
CP system
24 V DC (protected against
incorrect polarity)
20.4...26.4 V
Max. 250 mA
See manual CP system",
current consumption table
Pin 2
Load voltage connection
(outputs/valves)
 Rated value
 Tolerance
 Current consumption
24 V DC (protected against
incorrect polarity)
20.4...26.4 V
Sum of all switched−on CP
solenoid valves; see manual
CP pneumatics"
Residual ripple 4 Vpp (within tolerance)
Detailed information on the CP FB6−E can be found in the
manual P.BE−CP−FB6−E−.. .
