Festo CPX-CEC Series User Manual

Modular valve terminal with integrated controller CPX-CEC-...
9
Functionality/functions Supported
Watch and recipe
manager
Offline
mode
Insert -> New watch list Yes
Extras -> Rename watch list Yes
Extras -> Save watch list Yes
Extras -> Load watch list Yes
Online
mode
Extra -> Monitoring active Yes
Extras -> Write recipe Yes
Extras -> Read recipe Yes
Force values and write to watch manager Yes
Working area All functions Yes
Functionality/functions Supported/name
Target settings Target
Platform
Name Festo CPX-CEC/CPX-CEC-C1
Festo CPX-CEC-M1
Parameter size adapted to type Only relevant for X86
Functionality/functions Setting
Target settings Memory
Layout
Base, area Fixed setting
Size (code) 4 MB
Size per segment (global) 8 MB
Size (flag) 8 KB
Size (input) 8 KB
Size (output) 8 KB
Size, retain 30 KB
1)
Retain in own segment On
Total size of data memory 8 MB
Maximum number of global data segments 1
Maximum number of POUs 4096
1) 12 bytes are used by the run-time system, leaving 30708 bytes available for the application.
