1.3.2 Libraries
CoDeSys provided by Festo offers the following libraries for the Festo CoDeSys controller.
Library Description Source
Standard.lib Modules that the IEC61131-3 requires as standard
modules for an IEC programming system.
3S
– Standard
libraries for
CoDeSys
Util.lib Modules for BCD conversion, bit/byte functions,
mathematical help functions, controllers, signal
generators, function manipulators and analogue value
processing.
AnalyzationNew.lib Modules for analysing expressions.
IecSfc.lib ActionControl
3S_CanDrv.lib
3S_CANopenManager.lib
3S_CANopenMaster.lib
Only for internal use in combination with the CANopen
master.
3S
– CANopen
libraries
BusDiag.lib Diagnosis for CANopen bus systems. 3S
– Target
system-
specific
libraries that
are specially
adapted to the
CPX-CEC-....
SysLibCallback.lib
1)
SysLibCom.lib
SysLibDir.lib
SysLibEvent.lib
SysLibFile.lib
SysLibFileAsync.lib
SysLibFileStream.lib
SysLibGetAddress.lib
SysLibIecTasks.lib
SysLibMem.lib
SysLibPLCConfig.lib
SysLibProjectInfo.lib
SysLibRtc.lib
2)
SysLibSem.lib
SysLibSockets.lib
3)
SysLibSocketsAsync.lib
3)
SysLibStr.lib
SysLibSymbols.lib
SysLibTask.lib
SysLibTime.lib
SysLibVisu.lib
SysTaskInfo.lib
NetVarUdp_LIB_V23.lib
System libraries that provide access to the special
hardware and software functions of the Festo
CoDeSys controller (e.g. access to real-time clock, file
system, communication interfaces, etc.).
System libraries other than those listed are not
approved for the CPX-CEC-....
ModbusTCPSrv.lib
4)
Modules for communicating via Modbus TCP. 3S (additional
libraries)
– Modbus
libraries for
CoDeSys
