2. Commissioning
2-27
Festo P.BE-CTEU-PB-OP+MAINT-EN en 1208NH English
Address/
structure,
Use
obligatory/
optional
DescriptionDesignation, size
I&M18 …
I&M098
(65018 …
65098)
Profile-specific I&M functions Support through CTEU-PB: no Optional
I&M100 …
I&M199
(65100 …
65199)
Manufacturer-specific I&M
functions
Support through CTEU-PB: no Optional
Tab . 2/7: I&M data structures (data records)
– Module-related I&M data are not suppor ted.
– Every data structure always comprises 64 bytes.
– The I&M data structures are read with the “call service”
from the bus node or written into the device.
2.5.2 Load identification properties into the bus node using Step 7
1. Mark the bus node in HW Config.
2. Click on [Download Module Identification...] in the [PLC]
menu.
The corresponding dialogue window is displayed (see
Fig. 2/8).
3. Enter your identification properties into the data fields
under “Offline” (example, see Fig. 2/8).
4. Activate the checks under “Include” only for the data
fields for which you wish to load data into the bus node.
Deactivate checks for the already correctly filled-out data
fields in the “ONLINE” field, or they will be o verwritten!
