2. Commissioning
2-10
Festo P.BE-CTEU-PB-OP+MAINT-EN en 1208NH English
2.3 Installation o n a higher-level controller
2.3.1 Device master file (GSD) and symbol files
A device master file (GSD) is needed for configuration and
programming of the bus node with a programming unit or PC.
The GSD includes all required information for adjustment of
the bus node using configuration and programming software,
e.g. Siemens SIMA TIC STEP 7.
Procurement source Current GSD and symbol files can be found on the Festo web-
site at www.festo.com Suppor t/Downloads Search
“GSD”.
GSD files Y ou will require one of the following files for the bus node:
– FEST0D67.GSD (German version)
– FEST0D67.GSE (International version)
For some older controllers, the GSD file can be too large for
the available memory capacity. In this case, contact F esto's
Technical Hotline.
Contact data can be found on the Festo website at
www.festo.com Contact.
S ymbol files Use the following symbol files to represent the bus node and
its statuses in your configuration software:
Normal opera-
ting status
Diagnostic case S pecial operating
status
File: CTEU_PB.dib File: CTEU_PBD.dib File: CTEU_PBS.dib
Tab. 2/2: Symbol files for configuration software
