2. Commissioning
2-9
Festo P.BE-CTEU-PB-OP+MAINT-EN en 1208NH English
Electric modules Allocated address
space
IdentifierModule
indicator
1)
Designation OutputsInputsSiemensEN50170
Module
indicator
1)
Valve terminal
VTOC-Interlock /
VTUG-Interlock 33-48
valves with I-Port con-
nection
VAEM-L2-S_
PTL-48
0x13, 0x25 32DI 37 4bytes/(18
used I)
6bytes/48O
Valve terminal MPA-L
with I-Port connection
with 32 valves
VMPAL-
EPL-IP03 2
0x23 32DO 0 4bytes/32O
Valve terminal VTUB
with I-Port connection
3-8 valves
VTUB-12-8 0x20 8DO 0 1byte/8O
Valve terminal VTUB
with I-Port connection
9-16 valves
VTUB-12-16 0x21 16DO 0 2 bytes/16 O
Valve terminal VTUB
with I-Port connection
17-24 valves
VTUB-12-24 0x23 32DO 0 4 bytes/32 O
Valve terminal VTUB
with I-Port connection
24-35 valves
VTUB-12-35 0x25 37 0 6bytes/48O
Universal module with
64 inputs and outputs
Universal
module
64DIO
0x37 55 8bytes/64I 8bytes/64O
Universal module with
64 inputs
Universal
module 64DI
0x17 23 8bytes/64I 0
Universal module with
64 outputs
Universal
module
64DO
0x27 39 0 8bytes/64O
1)
Module identifier in the hardware configuration of the programming software
Tab. 2/1: Module over view and address allocation: bus nodes and examples for digital
input and output modules
