2. Commissioning
2-8
Festo P.BE-CTEU-PB-OP+MAINT-EN en 1208NH English
Electric modules Module
indicator
1)
Identifier Allocated address
space
Designation EN50170 Siemens Inputs Outputs
Bus node CTEU for
PROFIBUS-DP
CTEU-PB 0x00 0 – –
Valve terminal
CPV10-GE-PT-8 16
valves with I-Port con-
nection
CPV10-8 0x21 16DO 0 2bytes/16O
Valve terminal
CPV14-GE-PT-8 16
valves with I-Port con-
nection
CPV14-8 0x21 16DO 0 2bytes/16O
Input module CTSL M12 CTSL M12 0x11 16DI 2bytes/16I 0
Input module CTSL M8 CTSL M8 0x11 16DI 2bytes/16I 0
Valve terminal
VTUG-1-16 valves with
I-Port connection
VAEM-L1-S-
8-PT
0x21 16DO 0 2bytes/16O
Valve terminal
VTUG-17-32 valves
with I-Port connection
VAEM-L1-S-
16-PT
0x23 32DO 0 4bytes/32O
Valve terminal
VTUG-33-48 valves
with I-Port connection
VAEM-L1-S-
24-PT
0x25 37 0 6bytes/48O
Valve terminal
VTOC-Interlock /
VTUG-Interlock 1-16
valves with I-Port con-
nection
VAEM-L2-S_
PTL-16
0x13, 0x21 32DI 16DO 4bytes/
(1 8 used I)
2 bytes/16 O
Valve terminal
VTOC-Interlock /
VTUG-Interlock 17-32
valves with I-Port con-
nection
VAEM-L2-S_
PTL-32
0x33 32DX 4bytes/
(1 8 used I)
4 bytes/32 O
