2. Commissioning
2-39
Festo P.BE-CTEU-PB-OP+MAINT-EN en 1208NH English
Description of the status transitions
Status Designation Function
0
– Initialisation was successful.
1 Check Param OK Checking of the parameters was successful.
2 Check Config OK Checking of the configuration was successful (comparison of the con-
figuration set at the DP master with the actually existing configuration
in the bus node).
3 Reset communica-
tion
Aftertimeout ormalfunctionat the fieldbusorreset of communication,
fieldbuscommunicationis restarted, e.g. after the fieldbuscable is un-
plugged and plugged back in or the DP master is restarted.
4 Hardware reset After the bus node is re starte d, initialization of the bus node is started
anew.
Tab . 2/9: Status transitions – descriptions at Fig. 2/14
