No. Designation, type
1 Hexagon head screw, ISO 4017-M5×16-A2-70
2 Ring, 5.2×9×1-1.4301
3 Toothed disc, DIN 6797-J-5,3-A2-70
4 End cap
5 Moulded seal
6 Sliding ring
7 O-ring, 33×3.5-N-NBR70
8 Piston
9 Slide element
10 Housing
11 Sliding ring
12 Shim, DIN 988-12×18×1-A2
13 Retaining ring, DIN 471-12×1-A2
14 O-ring, I3601 B-9×2-N-NBR70
15 O-ring, I3601 B-13×2-N-NBR70
16 Mounting plate
17 Toothed disc, DIN 6797-J-5,1-A2-70
18 Socket head screw, DIN912-M5×12-A2-70
19 Sliding ring
20 Cam
21 O-ring, I3601 B-11×2-N-NBR70
22 Sliding ring
23 Shaft
24 Sliding ring
25 O-ring, 3601 B-14.5×2-N-NBR70
26 O-ring, I3601 B-5.28×1.78-N-NBR70
27 Ring, 6.2×12×1.5-1.4301
28 Hex nut, DIN 934-M6-A2-70
29 Regulating screw
30 Lubricant, SYNTHY POLYMER 402/2
3.1.1 DFPD-10 bill of materials
11 / 74DFPDb_en
