1 Important information
1.1 About these repair instructions
This document contains important information about proper repair of the quarter-turn actuator type DFPD.
Before carrying out a repair, these repair instructions must be read in full and followed.
Other documentation for this product:
– Operating instructions ( www.festo.com/sp)
– Spare parts documentation ( www.festo.com/spareparts)
1.2 Symbols used
1.2.1 Danger categories
The following symbol identies text passages which draw attention to specic hazards.
Warning
Marking of special information
The following symbols identify text passages which contain special information.
Note
1.2.2 Repair steps
Familiarise yourself with the meaning of the symbols before starting the repair work.
Warning
There is a risk of injury due to uncontrolled movements of components.
Reference arrow
Symbol indicating the individual components to be noted.
Linear movement arrow
Carry out a linear movement
Slow movement
Carry out the dismantling / assembly step slowly and carefully.
Reference to repair steps
Follow the given repair steps.
Attention
Pay particular attention to notes and information.
Visual inspection
Perform a visual inspection.
