Festo KBS-FEC FC30- 0206NH English 31
7. If you are using the FST software:
7.1. Create a new project and select the IPC FEC Com-
pact as the controller.
7.2. Open the I/O configuration and add an input
module and an output module, both with address
0.
7.3. Add a program and then insert the following lines
of code:
IF NOP
THEN LOAD IW0
TO OW0
7.4. Select the program from the project tree, compile
it and then download the project to the controller .
If you are not using COM1 on your programming
PC, then you must first switch to the COM port
that you are using.
7.5. Switch the controller to RU N (the R UN LED must
light up green). If you now apply a signal at the
input, the output with the same address must
switch to “1“.
