Festo FED-40 - 2 Technical Specifications

2 Technical Specifications
2-1 Festo FED-... en 1107g
2 Technical Specifications
Power supply
Power supply voltage 18 … 30 V DC
Power consumption
(1)
Back-up battery
(1)
3 V 270mA Lithium, not rechargeable,
life approx. 1 year, user replaceable,
model: CR2430 or equivalent with the work temperature of FED.
Fuse overcurrent protection device
Notes:
1) Feature depends on the panel models; see Table below. For FED-400, FED-770,
FED-3000 3V 50mAh Lithium, rechargeable, not user-replaceable, PANASONIC
model VL2330.
Environmental conditions
Operating temperature 0 - +50 C, with the exception of the model
indicated on note
(2)
EN 60068-2-14
Storage temperature -20 - +70 C EN 60068-2-14
Operating and storage humidity 5 - 85%RH non-condensing EN 60068-2-30
Vibration 10 - 57 Hz, 0,075 mm peak
57 - 150 Hz, 1 G
EN 60068-2-6
Shock 50 g, 11 ms, 3 pulses per axis EN 60068-2-27
Protection class Front IP65
(3)
Rear IP20
(3)
EN 60529
Keyboard reliability
>
3 million operations
Notes:
2) For FED-500, FED-550, FED-700, FED-710, FED-1000, FED-1010, FED-2000, FED-2010,
FED-3000, FED-5000, FED-5010 range 0 - +45°C
3) Please observe the installation instructions in the chapter “Installation
environment”
