2 Technical Specifications
Festo FED-… en 1107g
2-6
Model FED-550 FED-700 FED-710
Display TFT TFT TFT
Backlight LED CCFL CCFL
Graphics 320X240 640x480 640x480
Rows x Columns N.A N.A. N.A.
Display dimensions (mm) 115x86 154x116 154x116
Diagonal (inches) 5.7 7.5 7.5
User memory 32MB 32MB 32MB
Memory card Option Option YES
Function keys 1 1 1
System keys - - -
Touch screen YES YES YES
User LED’s 1 1 1
System LED’s 4 4 4
PC/printer port YES YES YES
PLC port YES YES YES
Ethernet Port YES YES YES
USB Port YES YES YES
AUX port YES YES YES
Programming speed Up to 38.400,
min. 9600
Up to 38.400,
min. 9600
N.A.
Battery YES YES YES
Recipe memory 32KB 32KB N.A.
Alarms 1024 1024 N.A.
Events list 1024 1024 N.A.
Hardware clock YES YES YES
Max. deviation of real time
clock/month
130 s 130 s 130 s
Downloadable characters 256 256 N.A.
Screen saver YES YES YES
Buzzer YES YES YES
Max. current consumption at
24 V DC (mA)
1000 1050 1050
Max. panel thickness (mm) 4 4 4
Weight (kg) 1.4 1.6 1.6
