2 Technical Specifications
2-5
Festo FED-… en 1107g
Model FED-400 FED-500 FED-501
Display TFT STN COLOR LCD
Backlight LED CCFL LED
Graphics 480x272 320x240 320x240
Rows x Columns N.A. N.A. N.A.
Display dimensions (mm) 96x54 121x91 121x91
Diagonal (inches) 4.3 5.7 5.7
User memory 2MB 32MB 32MB
Memory card - YES YES
Function keys - 1 1
System keys - - -
Touch screen YES YES YES
User LED’s - 1 1
System LED’s - 4 4
PC/printer port - YES YES
PLC port YES YES YES
Ethernet Port YES - -
USB Port YES - -
AUX port YES YES YES
Programming speed Up to 38.400,
min. 9600
Up to 38.400,
min. 9600
Up to 38.400,
min. 9600
Battery YES YES YES
Recipe memory 32KB 32KB 32KB
Alarms 1024 1024 1024
Events list 256 1024 1024
Hardware clock YES YES YES
Max. deviation of real time
clock/month
130 s 130 s 130 s
Downloadable characters 256 256 256
Screen saver YES YES YES
Buzzer - YES YES
Max. current consumption at
24 V DC (mA)
400 800 600
Max. panel thickness (mm) 5 4 4
Weight (kg) 1 1.4 1.4
