2 Technical Specifications
Festo FED-… en 1107g
2-4
Model FED-90 FED-300 FED-301
Display LCD TFT LCD MONO
Backlight LED LED LED
Graphics 120x32 320x240 320x240
Rows x Columns 4x20 16x40 16x40
Display dimensions (mm) 70x21 72x54 77x58
Diagonal (inches) 2.8 3.5 3.8
User memory 512KB 1MB 512KB
Memory card - - -
Function keys 12 - -
System keys 23 - -
Touch screen - YES YES
User LED’s 13 - -
System LED’s 4 - -
PC/printer port YES - -
PLC port YES YES YES
Ethernet Port - - -
USB Port - - -
AUX port YES YES YES
Programming speed Up to 38.400,
min. 9600
Up to 38.400,
min. 9600
Up to 38.400,
min. 9600
Battery YES YES YES
Recipe memory 16KB 32KB 32KB
Alarms 1024 1024 1024
Events list 256 256 256
Hardware clock YES YES YES
Max. deviation of real time
clock/month
130 s
130 s
130 s
Downloadable characters 256 256 256
Screen saver - YES YES
Buzzer - - -
Max. current consumption at
24 V DC (mA)
300
400
400
Max. panel thickness (mm) 5 5 5
Weight (kg) 1.1 1 1
