2 Technical Specifications
2-3
Festo FED-… en 1107g
Model FED-40 FED-50 FED-60
Display LCD LCD LCD
Backlight LED LED LED
Graphics 120x32 120x32 120x32
Rows x Columns 4x20 4x20 4x20
Display dimensions (mm) 70x21 70x21 70x21
Diagonal (inches) 2.8 2.8 2.8
Memory card - - -
User memory 512KB 512KB 512KB
Function keys 4 4 9
System keys 7 7 10
Touch screen - - -
User LED’s 5 5 10
System LED’s 4 4 4
PC/printer port - - -
PLC port YES YES YES
Ethernet Port - - -
USB Port - - -
AUX port - YES YES
Programming speed 9600 Up to 38.400,
min. 9600
Up to 38.400,
min. 9600
Battery - YES YES
Recipe memory - 16KB 16KB
Alarms 1024 1024 1024
Events list - 256 256
Hardware clock - YES YES
Max. deviation of real time
clock/month
- 130 s 130 s
Downloadable characters 256 256 256
Screen saver - - -
Buzzer - - -
Max. current consumption at
24 V DC (mA)
250 250 250
Max. panel thickness (mm) 5 5 5
Weight (kg) 1 1 1
