Festo FED-40 - Page 92

2 Technical Specifications
Festo FED-… en 1107g 2-8
Model FED-2000 FED-2010 FED-3000
Display TFT TFT TFT
Backlight CCFL CCFL CCFL
Graphics 800x600 800x600 1280x800
Rows x Columns N.A. N.A. N.A.
Display dimensions (mm) 246x184 246x184 288x181
Diagonal (inches) 12.1 12.1 13
User memory 32MB 32MB 64MB
Memory card Option YES -
Function keys 1 1 -
System keys - - -
Touch screen YES YES YES
User LED’s 1 1 1
System LED’s 4 4 4
PC/printer port YES YES YES
PLC port YES YES YES
Ethernet port YES YES YES
USB port YES YES YES
AUX port YES YES YES
Programming speed Up to 38.400,
min. 9600
N.A. Up to 38.400,
min. 9600
Battery YES YES YES
Recipe memory 32KB N.A. 32KB
Alarms 1024 N.A. 1024
Events list 1024 N.A. 1024
Hardware clock YES YES YES
Max. deviation of real time
clock/month
130 s 130 s 130 s
Downloadable characters 256 N.A. 256
Screen saver YES YES YES
Buzzer YES YES YES
Max. current consumption at
24 V DC (mA)
1300 1300 1400
Max. panel thickness (mm) 4 4 4
Weight (kg) 2.8 2.8 2.5
