2 Technical Specifications
2-9
Festo FED-… en 1107g
Model FED-5000 FED-5010
Display TFT TFT
Backlight CCFL CCFL
Graphics 1024x768 1024x768
Rows x Columns N.A. N.A.
Display dimensions (mm) 304x228 304x228
Diagonal (inches) 15 15
User memory 32MB 32MB
Memory card Option YES
Function keys 1 1
System keys - -
Touch screen YES YES
User LED’s 1 1
System LED’s 4 4
PC/printer port YES YES
PLC port YES YES
Ethernet port YES YES
USB port YES YES
AUX port YES YES
Programming speed Up to 38.400,
min. 9600
N.A.
Battery YES YES
Recipe memory 32KB N.A.
Alarms 1024 N.A.
Events list 1024 N.A.
Hardware clock YES YES
Max. deviation of real time
clock/month
130 s 130 s
Downloadable characters 256 N.A.
Screen saver YES YES
Buzzer YES YES
Max. current consumption at
24 V DC (mA)
1500 1500
Max. panel thickness (mm) 4 4
Weight (kg) 3.8 3.8
