Page #21 background imageLoading...
Page #21 background image
Festo SPCAIF−... 0506b English
21
5 Technical specifications
Type SPC−AIF−...
Dimensions (plug outlet upper
most; without cable; including
attachment bracket)
Width: approx. 100 mm
Height: approx. 42 mm
Length: approx. 66 mm
Weight Approx. 300 g
Temperature range:
Operation
Storage/transport
0 ... +50 °C
20 ... +70 °C
Relative atmospheric humidity 95 % non condensing
Protection class as per
EN 60529, Plug connector
plugged in or fitted with
protective cap
IP65
Power supply:
Nominal value
Tolerance
1)
Current consumption
including MPYE...
Current consumption
without MPYE...
Residual ripple
24 V (DC)
25 % ... + 25 %
SPC...−POT / ...LWG
SPC...MTS
1.1 A 1.2 A
2)
100 mA 200 mA
2)
Max. 6 %Max. 6 %
1)
Observe tolerance of type MPYE... valve when connected
2)
Current consumption including measuring system
