Festo SPC−AIF−... 0506b English
13
1 User instructionsEnglish
The axis interface type SPC−AIF−... is used to connect pneu
matic axes to the SPC200 Smart Positioning Controller. It
establishes the link with the MPYE−
... proportional direc
tional control valve and one of the following measuring
systems.
Axis interface type
Permitted measuring system type
SPC−AIF−POT MLO−POT−...−TLF or integrated systems
DNCM−... (analogue systems)
SPC−AIF−POT−LWG MLO−POT−...−LWG or integrated systems
DSMI−... (analogue systems)
SPC−AIF−MTS MME−MTS−...−TLF−AIF or integrated systems
DGPI−(L)...−...−AIF (digital systems)
Detailed information on the axis interface can be found in
the P.BE−SPC200−... User Manual.
Caution
Pay strict attention to the following instructions shown
therein:
 safety guidelines
 specifications for the use of each module and compo
nent.
Warning
Prior to any installation or maintenance work, switch off
the power sources in the following sequence:
1. Compressed air supply
2. Load supply and operating voltage supply for the
SPC200.
