Technical data
* Speed specifications with fully charged battery pack.
Intended use
Cordless drills are suitable for drilling into metal,
wood, plastics and similar materials as well as in-
serting and tightening screws.
The charger MXC is designed for charging the bat-
tery packs listed.
The charger is designed for internal use only.
Functional description
The pictures for the functional description are on a
fold-out page at the beginning of the instruction
manual. When reading of the manual you can fold
out this page for having always an overview of the
machine.
Cordless drill CXS
Motor voltage 10.8 V
Idling speed* 1st gear 0 - 400 rpm
2nd gear 0 - 1200 rpm
Max. torque
Soft material (wood) 10 Nm
Hard material (metal) 16 Nm
Adjustable torque 1st gear 0.2 - 2.4 Nm
2nd gear 0.2 - 2.4 Nm
Chuck clamping range 1 - 8 mm
Drill diameter max.
Wood 12 mm
Metal 8 mm
Tool holder in drill spindle 1/4 ’’
Weight without battery pack with Centrotec 0.7 kg
Charger MXC
Mains voltage (input) 120 V ~
Mains frequency 60 Hz
Charging voltage (output) 10.8 V=
Rapid charging typ. 2.8 A
Charging times for
LiIon 1,5 Ah, 80 %/ 100 % approx. 23/ 35 min
Permitted operating tempera-
ture range
-10 °C to + 40 °C
Temperature monitoring via NTC-resistor
Safety class /II
Battery pack XS-AS
Voltage 10.8 V
Capacity 1.5 Ah
Number of cells 3
Permitted battery temperature
for charging
0 °C to + 45 °C
Weight 0.2 kg
WARNING
The user bears the responsibility for damage and
accidents caused by improper use; this also in-
cludes damage and wear caused by continuous
use in industry.
[1-1]
Torque thumbwheel
[1-2]
Drilling symbol
[1-3]
Torque/drilling position marking
