18
DF700 EQ
See chapter
5. Mark the areas on the workpieces
that belong together [8-1] so that
you will be able to join them cor-
rectly again once you have cut the
dowel holes.
6. A Position the two workpieces to be
joined against one another and
mark the desired positions of the
DOMINO dowels with a pencil [8-1].
6. B Select the required stop pins 7.7
7. Set the desired dowel hole width
(adequate fit or with 3 mm play)
7.6
8. Cutting the dowel holes [8]:
– The first dowel hole by attaching
the stop pin to the side edge of
the workpiece.
– The following dowel holes
according to the previously made
pencil markings and the scale of
the vision panel [8-3].
Our recommendation: Please check
each dowel hole for chippings and
clear these if necessary.
Always work with a dust extractor to
improve the removal of chippings.
Route the first hole for each work-
piece without play (dowel hole width
= DOMINO dowel width) and the
other dowel holes with the large
dowel hole width.
9 Service and maintenance
WARNING
Risk of injury, electric shock
XAlways disconnect the mains plug from the
socket before performing maintenance work
on the machine!
XAll maintenance and repair work which re-
quires the motor housing to be opened must
only be carried out by an authorised service
workshop.
Customer service and repair. Only
through manufacturer or service work-
shops: Please find the nearest address
at: www.festool.com/Service
1
2
3
5
4
Use only original Festool spare parts!
Order No. at: www.festool.com/Service
The machine is equipped with special carbon
brushes. If they are worn out, the power is
interrupted automatically and the machine comes
to a standstill.
Observe the following instructions:
XTo ensure constant air circulation, always keep
the cooling openings in the housing unobstruct-
ed and air accessible.
XClean the guides [3-1] and [3-6] of dust
deposits.
XOil the guides regularly and lightly with resinfree
oil (e.g. sewing machine oil).
We recommend an annual inspection and/
or a check after approx. 100 operating
hours at an authorised customer service
workshop. This is for the safety of the user
and the value stability of the power tool.
10 Accessories
The order numbers of the accessories and tools
can be found in the Festool catalogue or on the
Internet under “www.festool.com”.
Festool provides comprehensive accessories
which allow you to use your machine effectively
and for diverse applications, e.g.:
• Handrail fence RA-DF 500/700
• Cross stop QA-DF 500/700
• Stopper LA-DF 500/700
Assembly instructions are included at the end of
the operating manual.
11 Environment
Do not dispose of power tools in house-
hold waste! Recycle devices, accesso-
ries and packaging. Observe applicable
country-specific regulations.
