5 Technical data
Cordless drywall screwdrivers DWC 18-2500 DWC 18-4500
Motor voltage 18 V 18 V
No-load speed*
0–2500 min
-1
0–4500 min
-1
Torque soft/hard 7/18 Nm 5/14 Nm
Chuck 1/4" DIN 3126/ISO 1173 1/4" DIN 3126/ISO 1173
Max. workable screw length 55 mm (2-3/16") 55 mm (2-3/16")
Weight (incl. battery pack and magazine attach
ment) as per EPTA procedure 01:2014
4.4 lbs (2 kg)
Weight excl. battery pack 2.6 lbs (1.2 kg)
Weight excl. battery pack, incl. depth stop 2.9 lbs (1.3 kg)
Weight excl. battery pack, incl. magazine at
tachment
3.5 lbs (1.6 kg)
* Speed values based on fully charged battery
pack.
6 Functional description
[1-1]
Bit store
[1-2]
On/off switch
[1-3]
Rotational direction switch
[1-4]
AUTO/MAN selector switch
[1-5]
Depth stop
[1-6]
Bit
[1-7]
Insulated gripping surfaces (grey
shaded area)
[1-8]
Capacity display button on battery pack
[1-9]
Capacity indicator
Accessories shown or described are not always
included in the scope of delivery.
The pictures for the functional description are
on a fold-out page at the beginning of the in
struction manual. While reading the manual
you can fold out the page for comparison and
quick reference.
7 Commissioning
7.1 Changing the battery pack
Inserting the battery pack [2A]
Removing the battery pack [2B]
The battery pack is ready to use straight out of
the box and can be charged at any time.
English
10
