10
Power supply and start-up
Always switch the machine off before con-
necting or disconnecting the mains power
cable!
The network voltage must conform to the voltage
indicated on the rating plate. A 16 A safety fuse (for
120 V) or a corresponding protective circuit-breaker
is required.
Connecting and detaching the mains power cable
-
see Fig.
[2]
.
Extension Cord
If an extension cord is required, it must have suffi-
cient cross-section to prevent an excessive drop in
voltage or overheating. An excessive drop in voltage
reduces the output and can lead to failure of the
motor. The table below shows you the correct cord
diameter as a function of the cord length for this
tool.
Use only U.L. and CSA listed extension cords.
Never use two extension cords together. Instead,
use one long one.
The lower the AWG number, the stronger the
cord.
Switch on/off
WARNING!
Keep the machine steady during
switching and during use by holding the ma-
chine with two hands, one on the motor
housing and one on the gear head or additional
handle
[1-6]
.
The switch
[1-9]
is an on/off switch (I = ON, 0 =
OFF).
Settings
Electronics
The machine features full-wave electronics with
the following features:
Smooth start-up
The electronically controlled smooth start-up en-
sures that the machine starts up jolt-free.
Speed adjustment
You can regulate the speed steplessly between
10000 and 26000 rpm using the adjusting wheel
[1-
8]
. This enables you to optimise the cutting speed to
suit the material.
Constant speed
The motor speed remains constant through elec-
tronic control to ensure a uniform cutting speed
even when under load.
Temperature control
To prevent overheating, the safety electronics
switches the machine off when it reaches a critical
motor temperature. Let the machine cool down for
approx. 3–5 minutes before using it again. The ma-
WARNING
Unauthorised voltage or frequency!
Risk of accident
The mains voltage and the frequency of the pow-
er source must correspond with the specifica-
tions on the machine's name plate.
In North America, only Festool machines with
the voltage specifications 120 V/60 Hz may be
used.
Total Extension Cord
Lenght (feet)
25 50 100 150
Cable size (AWG) 18161614
WARNING
Risk of injury, electric shock
Always pull the mains plug out of the socket be-
fore performing any type of work on the ma-
chine!
