Guide types
Routing with ball bearing guide [6]
When routing with cutters with a ball bearing guide
the ball bearing brake must be inserted in the edge
router. The edge router is guided so that the ball
bearing guide of the cutter rolls between the brake
and edging.
Adapt height of the brake to the height of the
ball bearing guide - 2 stages [7] .
Routing with plane cutter [8]
The ball bearing brake is not used when routing
with plane cutters. Guide edge router so that the
stop of the router table is at the edging - also pos-
sible at diagonal edges.
Metal processing
When processing metal, the following mea-
sures must be taken for safety reasons:
– Install an upstream residual-current circuit-
breaker (FIG, PRCD).
– Connect the machine to a suitable dust extractor.
– Regularly remove dust deposits in the motor
housing.
6
+
7
8
+
