duce your exposure to these chemicals: work in
a well ventilated area, and work with approved
safety equipment, such as dust masks that are
specially designed to filter out microscopic par
ticles. Wash hands after handling.
WARNING
TO REDUCE THE RISK OF INJURY, USER
MUST READ INSTRUCTION MANUAL.
4 Intended use
Cordless impact drill suitable
– for drilling in metal, wood, plastics and
similar materials,
– for impact drilling in brickwork, masonry
and stone,
– for screwing in and tightening screws.
– intended for use with BP Festool battery
packs of the same voltage class.
The user is liable for damage and acci
dents caused by improper and non-in
tended use; this also includes damage and
wear caused by continuous industrial operation.
5 Technical data
Cordless impact drill TPC 18/4
Motor voltage 18 V
No-load speed* 1. gear
0 - 500 min
-1
2. gear
0 - 800 min
-1
3. gear
0 - 2350 min
-1
4. gear
0 - 3600 min
-1
Max. torque Soft material (wood) 50 Nm
Hard material (metal) 75 Nm
Adjustable torque** 1st gear/2nd gear 2–20 Nm
Chuck clamping range 1/16" - 1/2" (1.5–13 mm)
Max. drill diameter Wood 2-3/4" (70 mm)
Metal 1/2" (13 mm)
Masonry (tiles) 3/8" (10 mm)
Screwdriving in spruce Max. ∅ 3/8" (10 mm)
Tool holder in drill spindle 1/4"
Weight as per EPTA Procedure 01:2014 (with auxiliary handle,
BP 18 Li 6.2 AS battery pack and chuck)
5.7 lbs (2.6 kg)
Weight incl. Centrotec, excl. auxiliary handle and battery pack. 3.1 lbs (1.4 kg)
* Speed values based on fully charged battery pack.
** The maximum speed (value for clockwise rotation) is reduced in the lower torque settings.
6 Functional description
[1-1]
Buttons for releasing the battery pack
[1-2]
Capacity indicator button on battery
pack
[1-3]
Capacity indicator
[1-4]
LED light
[1-5]
On/off switch
[1-6]
Collar
[1-7]
Auxiliary handle
[1-8]
Drilling/impact drilling selector
switch
[1-9]
Gear switch
English
10
