Festool TPC 18/4 - Depth Stop

KC 13
1
2
klick
klick
klick
klick
3
4
8
10.3 Angle attachment [9]
Drilling and screwdriving at right angles to the
power tool (available as an accessory depend
ing on the model).
AN-UNI
3
2
1
9
10.4 Tool holder in the drill spindle [10]
Bits can be inserted directly into the hexagon
socket holder of the drill spindle.
10
10.5 Eccentric adapter
[11]
Screwdriving close to edges with bits according
to ISO 1173 (available as an accessory depend
ing on the model).
EX-UNI
3
2
1
11
10.6 Depth stop
[12]
The depth stop (available as an accessory de
pending on the model) allows a screw to be
tightened with a defined depth. You can set the
dimension to which the screwhead is to project
over the workpiece surface, or to which it is to
be inserted.
Depth adjustment
Firmly set the required screw-
in depth by turning the hous
ing [12-1]. Each catch alters
the screw-in depth by 0.004" (0.1 mm).
To unscrew a screw, the A/B sleeve must first
be removed.
English
14
