1101.00131.00 CBS-2132, 2 X 3kW/240VAC, 1gal BYPASS
Ref# Qty
1 1 1111.00029.00 WELDMENT BODY, CBS-2132
2 2 1024.00049.00 EDGE PROTECTOR, 7.00"LG, CBS-2130
3 6 1086.00004.00 BUSHING, SNAP, 1" MOUNTING HOLE
4 2 1024.00017.00 O'RING, 3.739" ID X 0.070" CS, 70 DURO, BUNA
5 2 1102.00183.00 SPRAY HOUSING ASSEMBLY, CBS-2130
6 8 1083.00010.00 WASHER, #10 SCREW W/NEOPRENE-BONDED SEAL
7 12 1084.00006.00 NUT, 8-32 18-8 HEX MACHINE SCREW
8 2 1102.00113.00 SWITCH, REED, ASSEMBLY
9 6 1029.00006.00 #4-40 NYLON FINGER NUT
10 1 1071.00010.00 FAUCET HPSC-BR-8 REGULAR HANDLE
11 1 1031.00003.00 FITTING, BARB 3/8'ID x 1/4" FPT
12 1 1057.00043.00 SOLENOID VALVE, SINGLE, 180 DEG, 24VDC
13 1
14 2 1083.00005.00 WASHER, M4 18-8 INTERNAL TOOTH LOCKWASHER
15 2 1082.00010.00 SCREW, M4x10 ZINC PLATED PAN PHILLIPS MACHINE
16 1 1102.00164.00 ADAPTER ASSY, 3/4" BSP X 1/4 SAE FLARE
17 1 1104.00044.00 TANK ASSY, 2 X 3000W/240VAC, CBS-2132, GROMMETS
18 1 1112.00163.00 WELDMENT TANK LOCK BRACKET, CBS-2100
19 4 1083.00011.00 WASHER, #8 SCREW SIZE, INTERNAL TOOTH LOCK
20 2 1082.00023.00 SCREW, #8-32 X 3/8 TRUSS HD PHIL., MACHINE
21 1 1102.00187.00 PUMP BRACKET AND HOLDER ASSEMBLY
22 2 1024.00048.00 Y-CONNECTOR
23 4 1055.00001.00 PUMP, HOT LIQUID
24 12 1086.00003.00 UNICLAMP, 15.9 HOSE OD CLAMP
25 4 1025.00012.00 TUBE, 5/16'OD X 3/16"ID X 11.00"LG
26 1 1029.00002.00 FITTING, HOSE BARB TEE, SIZE 3/8" , NYLON
27 1 1025.00060.00 TUBE, 9/16'OD X 5/16"ID X 3.25"LG
28 1 1025.00061.00 TUBE, 9/16'OD X 5/16"ID X 2.75"LG
29 1 1025.00058.00 TUBE, 9/16'OD X 5/16"ID X 25.00"LG
30 1 1025.00063.00 TUBE, 5/8'OD X 3/8"ID X 8.50"LG
31 1 1102.00181.00 ASSEMBLY BACK PANEL, CBS-2130
32 11 1082.00017.00 SCREW, # 6-32 X 1/2" TRUSS HD PHIL., MACHINE
33 1 1023.00147.00 PLUG, TANK SERVICE DRAIN FOR 18GA AND UP BODY
34 1 1024.00040.00 CARD PLUG, HWD-2100
35 1 1102.00190.00 ASSEMBLY FRONT PANEL, CBS-2100
36 4 1082.00058.00 SCREW, # 8-32 X 5/8, FLAT HD, PH, 18-8 SS
37 2 1102.00182.00 ASSEMBLY, LOCATOR CBS-2130
38 2 1082.00065.00 SCREW #8-32 X 1 1/2", FLAT HD PH, 18-8 SS
39 2 1023.00159.00 CORNER INSERT
40 1 1112.00167.00 WELDMENT, TOP COVER, CBS-2132
41 3 1023.00163.00 LEG BODY, CBS-2130
42 3 1083.00021.00 WASHER, 1/4" SCREW SIZE, SPRING LOCK
43 3 1112.00158.00 WELDMENT, LEG ROD, CBS-2130
44 3 1021.00017.00 LEG INSERT THREADED, CBS-2130
45 1 1402.00032.00 HARNESS, HIGH AMP, CBS-2132
46 1 1402.00033.00 HARNESS, LOW AMP, CBS-2132
47 2 B012280B1 BB ASSY, 13"X5", .280" DIA. HOLE, BLK HNDL
48 2 1086.00002.00 CLAMP, HOSE, SIZE "G" NYLON
49 1 1083.00009.00 WASHER, #6 SCREW , INTL TOOTH LOCKWASHER
50 1 1084.00010.00 NUT, HEX, #6-32, UNDERSIZED, ZINC PLATED
51 2 1025.00006.00 TUBE, VENT SUPPORT, 5/16" OD X 3/16" ID X 1/
52 2 1025.00064.00 TUBE, 1/2 OD X 1/4 ID X 9.00 LG
53 2 1013.00073.00 TUBE, 5/16" OD, 1" LONG
