31
TANK ASSY, 2 X 3000W/240VAC, CBS-2132, GROMMETS
REF# QTY PART NO DESCRIPTION
1 1 1114.00062.00 WELDMENT TANK CBS-2132e, GROMMET DESIGN
2 2 1024.00053.00 GROMMET, SILICONE, LL & TEMP. PROBES
3 6 1024.00050.00 GROMMET, SILICONE, 11.4mm ID
4 1 1024.00051.00 GROMMET, SILICONE, BLANK
5 2 1107.00018.00 HEATER ASSEMBLY, IMMERSION 3000W/240VAC
6 1 1003.00005.00 BRACKET, ONE SHOT THERMOSTAT
7 1 1053.00003.00 THERMOSTAT, SINGLE SHOT, 240V/40A
8 2 1083.00009.00 WASHER, #6 SCREW , INTL TOOTH LOCKWASHER
9 2 1084.00010.00 NUT, HEX, #6-32, UNDERSIZED, ZINC PLATED
10 2 1003.00140.00 ALUMINUM BRACKET FOR SSR
11 2 1052.00016.00 ASSEMBLY RELAY, SOLID STATE, 50A/600VAC
12 4 1081.00042.00 STANDOFF, 6-32 x1.25 LG.,1/4 HEX WIDTH
13 1 1112.00002.00 PROBE WELDMENT, WATER LEVEL 2.25" LG
14 1 1102.00161.00 PROBE ASSEMBLY, TEMP. AND LLC, HWD-2100
15 1 1024.00007.00 O-RING, DASH #344, TANK COVER
16 1 1102.00007.00 TANK COVER ASSEMBLY
17 2 1023.00167.00 FITTING, BREW, GROMMET DESIGN
18 1 1023.00168.00 FITTING, HOT WATER, GROMMET DESIGN
19 1 1023.00166.00 FITTING, COLD WATER INLET, GROMMET DESIGN
20 1 1022.00057.00 TANK INSULATION, CBS-2132e, GROMMET DESIGN
21 6 1065.00006.00 CONNECTOR, TAB, .250", FASTON
22 1 1044.00004.00 LABEL, DANGER, HIGH VOLTAGE
