32
CBS-2100 Series Brew Basket Assembly, 13” X 5”, Part # B012280B1 (SQUARE)
1102.00183.00 PCSD Pump Spray Housing Assembly
Parts
Ref. QTY PART NO DESCRIPTION
1 1 1102.00020.00
SPRAY HOUSING ASSY&
MAGNETS, CSD DESIGN
2 1 1024.00045.00
O-RING, 5/8 X 13/16, 3/32
3 1 1023.00164.00
SPRAY HOUSING ADAPTER
4 2 1082.00068.00
SCREW, M3.9x13, CHEESE PH.,
T/FORM
5 1 1102.00019.00
CASCADE SPRAY DOME
ASSEMBLY
Complete CBS-2130 Spray Housing Assembly
-Part number 1102.00183.00
Ref# Qty Part Number Description
1 1 1112.00073.00 BB WLDMNT, 13"X5", W/ Ø.280 HOLE
2 1 1102.00064.00 HANDLE W/MAGNET ASSEMBLY, BLACK RUBBER
3 1 1082.00040.00 SCREW, 1/4-20 X .5, FL HD, PH., W/NYLON
4 1 1009.00006.00 BASKET, WIRE, 13" X 5", CBS-2040'S
5 1 1046.00025.00 LABEL, BREW BASKET WARNING
Never strike or hit a
brewbasket against
any hard surface
