41
Drawing 1102.00213.00 ASSEMBLY, BACK PANEL, CBS-2131/41, CE
1 1 1112.00236.00 WELDMENT BACK COVER, CBS-2131, 41 EU
2 4 1083.00011.00 WASHER, #8 SCREW SIZE, INTERNAL TOOTH LOCK
3 4 1084.00006.00 NUT, 8-32 18-8 HEX MACHINE SCREW
4 1 1058.00024.00 SWITCH, POWER, DOUBLE POLE, 16A, 125/250 VAC
5 1 1112.00246.00 WELDMENT BRACKET TERMINAL BLOCK, 3 POLE
6 1 1052.00022.00 EUROSTRIP HE6 TERM. BLK., 3 POLE, 40AMP,10-20 TERM. BLK.
7 1 1052.00025.00 MARKING PLATE BLANK FOR EUROSTRIP HE10, 1.750" LG.
8 2 1082.00082.00 SCREW, PHILLIP HD., 8-32 THREAD
9 1 1046.00030.00 LABEL WARNING, DISCONNECT FROM POWER SOURCE
10 1 1003.00170.00 BRACKET, GUARD
11 8 1081.00006.00 SPACER, 6MM OD x 3.2MM ID x 5MM LG, Z/P
12 1 1052.00001.00 POWER SUPPLY, 90-264VAC/24VDC, 1.8A
13 4 1029.00012.00 SPACER, .25" HEX X 1" LG, FEM #4-40 THREAD
14 1 1086.00029.00 BUSHING, STRAIN RELIEF, .360"-.430" DIA CABLE
15 1 1065.00009.00 GROUND LUG CONNECTOR, 14-2 AWG, ALUMINUM
16 1 1044.00013.00 LABEL EQUIPOTENTIALITY CE
