www.fetco.com
User’s Guide and Operator Instructions
CBS-5000H Series Coffee Brewers
Models:CBS-51H15;CBS-52H15; CBS-52H20
FETCO Commercial Beverage Equipment
Center: Dual 1½ Gal CBS-52H15
Left: Single1½ Gal CBS-51H15 Right: Dual 2 Gal CBS-52H20
Contact Information
FETCO®
Food Equipment Technologies Company
600 Rose Road
Lake Zurich • IL • 60047-1560 • USA
© 2008-2019 Food Equipment Technologies Company
Internet: www.fetco.com
Phone: (800) 338-2699 (US & Canada)
(847) 719-3000
Fax: (847) 719-3001
Email: sales@fetco.com
techsupport@fetco.com
CBS-5000H Legacy Handle Operated Brewers P183 MARCH 2019
fetco.com

Table of Contents

Questions and Answers

  • C
    Christopher HarringtonSep 13, 2025
    What causes short brew levels sometimes in Fetco Brewing Systems?
    • K
      kellie87Sep 14, 2025
      If you're experiencing short brew levels *sometimes* with your Fetco Brewing Systems, it could be due to: * **Water Filter:** Replace the water filter, especially if the problem worsens during simultaneous brews. * **Dispense Latch Assembly:** Replace the dispense latch assembly if it's weak (usually buzzing during the cycle). * **Water Pressure/Flow Rate:** Ensure the brewer has a dedicated water line, the shut-off valve is fully open, and increase the water line diameter or find a stable source if pressure/flow is too low or fluctuates.
  • S
    Sarah GilmoreAug 23, 2025
    Why Fetco Coffee Maker brew handle stays down but no water is dispensed?
    • C
      Caitlin AllenAug 23, 2025
      If the brew handle of your Fetco Coffee Maker stays down but no water is dispensed, the issue might be that no water is reaching the brewer. Ensure that the shut-off valve is open. Inspect the water line for any kinks and replace the line if necessary. Also, check to see if the filter is clogged by changing it.
  • C
    Christopher ClarkAug 27, 2025
    What causes short brew levels in Fetco Brewing Systems?
    • J
      Jorge KaiserAug 27, 2025
      Short brew levels in your Fetco Brewing Systems can stem from several issues: * **Flow Discs:** Ensure the flow discs in the spray heads are correctly assembled, with the bumps on the spray cutter facing the flange on the flow disc. * **Water Filter:** A clogged water filter can restrict flow. * **Spray Head:** A clogged spray head can also cause short brew levels; clean or replace it. * **Timer Settings:** Verify that the timers are set to the proper level. * **Incoming Voltage:** Low incoming voltage can affect timer function; reset the wall circuit breaker and consult an electrician to address loose connections.
  • P
    parkerdianaAug 30, 2025
    Why does my Fetco Brewing Systems coffee taste too strong?
    • K
      Kenneth KnightAug 31, 2025
      If your coffee brewed with Fetco Brewing Systems tastes too strong, it could be due to: * **Incorrect Dosage:** Make sure you are using the correct amount of coffee grounds. * **Short Brew Levels:** Refer to the troubleshooting steps for "Short brew levels".
  • S
    Shirley DunlapSep 1, 2025
    What causes weak coffee in Fetco Brewing Systems?
    • R
      Renee LopezSep 1, 2025
      If you're experiencing weak coffee with your Fetco Brewing Systems, here are a few potential causes: * **Missing Spray Head:** Ensure the spray head assembly is properly attached. * **Improper Dose:** Verify you're using the correct amount of coffee grounds. * **Filter Papers:** Make sure you're only using one filter paper. * **Cracked Dispense Tube:** Refer to the "spray head drips MAJOR" section for troubleshooting. * **Low Brew Temperature:** Adjust the thermostat to ensure the water stream at the bottom of the brew basket is 190 degrees + or - 5 degrees during brewing.
  • D
    Daniel BauerSep 3, 2025
    Why are grounds not saturated in Fetco Brewing Systems?
    • C
      Christopher ReevesSep 3, 2025
      If the grounds are not saturated in your Fetco Brewing Systems, consider these factors: * **Missing Spray Head:** Ensure the spray head is in place. * **Half Batch Usage:** Use a smaller “half batch” brew basket. Consider the need for a smaller brewer. * **Water Softener:** If using a water softener, switch the brewer's water feed to a non-softened source. * **Degassing:** If using extremely fresh coffee, call FETCO Service Dept. to discuss.
  • W
    William Duran Jr.Nov 25, 2025
    Why is my Fetco Brewing Systems brew water cold and the ready light is off?
    • C
      Cheryl SweeneyNov 25, 2025
      If your Fetco Brewing System's brew water is cold and the ready light is off, first ensure the water tank refills when water is dispensed, as the brewer won't heat without a full tank. Then, consider these possible causes: * **Power Issues:** Ensure the power switch is on, reset the machine circuit breaker, check the power connection, and verify the building circuit breaker. * **Liquid Level Control Board:** With power on and the water tank full, check the LLC board for 120 volts on the brown wire and neutral. If there's no voltage, replace the LLC board. * **Solid State Relay Connections:** Inspect the relay for burned or loose connections, replacing connectors if needed. * **Defective Solid State Relay:** Check input and output voltages on the relay. If there's 120 volts on the ...
  • M
    Maria WilliamsDec 1, 2025
    What to do if Fetco Brewing Systems brewer won’t stop brewing?
    • R
      Rebecca RoweDec 1, 2025
      If your Fetco Brewing System won’t stop brewing, consider the following: * **Dispense Tube:** Consult the “sprayhead drips MAJOR” section for guidance, as a cracked dispense tube can cause this issue. * **Mechanical Binding:** Re-align the brew handle, brass sprayhead tower, and dispense tube into a straight line by moving the brass tower if there is mechanical binding. * **Water Pressure:** If water pressure exceeds 75psi, install a water pressure regulator to reduce it to 20-75 psi. * **Dispense Tube Drive Screw:** Ensure the drive screw is straight and properly connects the handle to the dispense tube at the brass sprayhead tower. * **Water Level Probe:** Clean lime buildup on the probe tip and/or tank wall. Try grounding the probe wire to the brewer's body to see if it stops...
  • J
    jeffreybennettSep 12, 2025
    Why brew time required to fill LUXUS are not the same for both sides in Fetco Brewing Systems?
    • M
      Mary MannSep 12, 2025
      If the brew time required to fill LUXUS is not the same for both sides on your Fetco Brewing Systems, it could be because: * **Brewer Level:** Ensure the brewer is level front to back and left to right by adjusting the feet with an accurate level.
  • S
    shari18Sep 9, 2025
    What causes high brew levels in Fetco Brewing Systems?
    • B
      brianrobertsonSep 9, 2025
      High brew levels in your Fetco Brewing Systems can be attributed to: * **Timer Settings:** Adjust timers down to the appropriate level. * **Thermal Server:** Make sure the thermal server is empty before brewing.

Fetco CBS-5000H Series Specifications

General IconGeneral
BrandFetco
ModelCBS-5000H Series
CategoryCoffee Maker
LanguageEnglish
