FGH 2000 Series - Coded Data Fields

14 SERIES 2000 COMMUNICATIONS MANUAL
M41 Issue 1.1
3.15 Coded data fields.
3.15.1 Alarm type codes.
Reading and writing the controller alarm types is possible by use of parameters
P
(alarm 1)
and
S
(alarm 2) where the data field of the message is coded as follows.
DATA FIELD S2000 ALARM TYPE P2000 ALARM TYPE
0000 HIGH ALARM HIGH ALARM
0001 LOW ALARM LOW ALARM
0002 INDEXED ALARM INDEXED ALARM
0003 INDEXED HIGH ALARM INDEXED HIGH ALARM
0004 INDEXED LOW ALARM INDEXED LOW ALARM
0005 MANUAL ACK' RELAY MANUAL ACK' RELAY
0006 REMOTE SP ACK' RELAY REMOTE SP ACK' RELAY
0007 INVALID PROGRAM RELAY
0008 INVALID READY RELAY
0009 INVALID UP RAMP RELAY
0010 INVALID DOWN RAMP RELAY
0011 INVALID SOAK RELAY
3.15.2 Setpoint type codes.
The setpoint type (parameter code
O
) is coded as follows.
DATA FIELD SETPOINT TYPE
0000 HIGH CLAMPED SETPOINT
0001 LOW CLAMPED SETPOINT
0002 INDEXED SETPOINT
0003 REMOTE SETPOINT
0004 INTERNAL SETPOINT
3.15.3 Ratio limit reference type codes.
The ratio limit 1 reference (parameter code
I
) is coded as follows.
DATA FIELD RATIO REFERENCE TYPE
0000 LIMIT IS OFF
0001 LOAD
0002 SETPOINT
