3.8 Programmer read/write parameter codes
The table below shows the meaning of all the parameter codes available in the profile
generator.
PARAMETER
CODE
SS
FIELD
MEANING READ
ONLY
DATA
FIELD
C N/A Profile setpoint YES TYPE 1
D N/A Delay start time in mins NO TYPE 1
E N/A Segment Elapsed time in mins YES TYPE 1
H N/A Profile hold band in digits NO TYPE 1
I N/A Profile hold type NO TYPE 1
(coded)
J N/A Profile repeats NO TYPE 1
K N/A Number of repeats remaining YES TYPE 1
L YES Segment target level in digits NO TYPE 1
M N/A Current event status YES TYPE 4
N N/A Ready mode event status NO TYPE 4
P N/A Profile pointer NO TYPE 1
Q N/A Profile status YES TYPE 5
R YES Segment event outputs NO TYPE 4
T YES Segment time in minutes NO TYPE 6
X N/A Profile currently running YES TYPE 1
3.9 Controller Set status codes.
Writing a set command to the instrument with a parameter as follows will produce the
specified action if the address field matches the address of the instrument. In the examples
given the instrument address is assumed to be 20.
CODE MESSAGE REPLY
MEANING
M S20M<CR> *20M<CR> Set controller to Manual mode
A S20A<CR> *20A<CR> Set controller to Auto mode
P S20P<CR> *20P<CR> Turn on the pretuner
T S20T<CR> *20T<CR> Turn on the adaptive tuner
O S20O<CR> *20O<CR> Turn off pretuner and adaptive tuner
U S20U<CR> *20U<CR> Unlatch any latched alarms
