FGH 2000 Series - Page 8

SERIES 2000 COMMUNICATIONS MANUAL 7
M41 Issue 1.1
Please note that some parameters use coded data fields, the code meanings are listed
after the table.
Code R/W Parameter Scroll
Element
Data field
type
@ R/W Comms remote setpoint - 1
A R Measured variable - 1
B R/W Output in 0.1%
Desired valve position
OP
OP
1
1
C R/W Local setpoint SP-L 1
D R/W Propband in 0.1%
Ratio in 0.1%
ProP
rAt
1
1
E R/W Integral action time in S
Ratio low setpoint output limit
IAt
LoOP
1
1
F R/W Derivative action time in S
Ratio low thermal head limit
dAt
tHLo
1
1
G R/W Derivative approach band in Xp
Ratio approach band
APr
bAnd
1
1
H R/W Heat high power limit in 0.1%
Ratio high air setpoint limit
H-PL
HiOP
1
1
I R/W Heat TP cycle time in S
Ratio positive reference type
HCyC
rEFH
1
1
J R/W Alarm 1 level ALr1 1
K R/W Alarm 2 level ALr2 1
L R Controller status - 2
M R/W User Retransmit value - 1
N R Resultant (control) setpoint - 1
O R/W Setpoint type code StyP 1
P R/W Alarm 1 type code A1ty 1
Q R Instrument type code - 3
R R Analogue remote setpoint value - 1
S R/W Alarm 2 type code A2ty 1
T R/W Heat low power limit in 0.1%
Cool high power limit in %
Ratio max thermal head
L-PL
C-PL
tHHi
1
1
1
U R/W Setpoint ramp rate in digits/hour rAtE 1
V R/W Cool TP cycle time in S
Valve action time in S
Ratio negative reference type
CCyC
VAt
rEFL
1
1
1
W R/W Cool relative prop band in 0.1 rEL 1
X R/W Heat/Cool deadband in 0.1%
Motor valve deadband in 0.1%
dbnd
dbnd
1
1
Y R/W Auxiliary setpoint 1 SP1 1
Z R/W Auxiliary setpoint 2 SP2 1
