Cav-
ity
Maxi
Fuse
Mini
Fuse
Description
F09 5 Amp
Tan
Air Electric Heater
Charge Indicator
F10 10 Amp
Red
Horn
F11 10 Amp
Red
Electronic Vehicle
Control Unit (EVCU)
F14 5 Amp
Tan
High beam (Shutter)
F15 15 Amp
Blue
Cigar Lighter
F16 10 Amp
Red
Humidity Sensor
VPAM
F18 5 Amp
Tan
Electronic Vehicle
Control Unit (EVCU)
F19 10 Amp
Red
HVAC
Cav-
ity
Maxi
Fuse
Mini
Fuse
Description
F20 15 Amp
Blue
Heated Seats – If
Equipped
F23 20 Amp
Yellow
Anti-Lock Brake
Valves
F24 7.5 Amp
Brown
EPS
YAW Sensor
F30 15 Amp
Blue
Fog Lamps
F81 30 Amp
Green
Electronic Shifter
(ESM)
F82 30 Amp
Green
Sunroof
F84 25 Amp
Clear
Regen Brake Module
308 MAINTAINING YOUR VEHICLE
