Cav-
ity
Maxi
Fuse
Mini Fuse Description
FTP3 25 Amp Clear Batt Coolant Pump
FPT5 20 Amp
Yellow
Inverter Coolant Pump
FTP9 10 Amp Red Battery Pack Control
Module (BPCM)
Power Inverter
Module (PIM)
FTP13 10 Amp Red EAC (AC Compressor)
On Board Charging
Module (OBCM)
FTP16 5 Amp Tan Intelligent Battery
Sensor (IBS)
FPT17 10 Amp Red EAC (AC Compressor)
Radiator Fan
FPT20 10 Amp Red Electronic Vehicle
Control Unit (EVCU)
VEHICLE STORAGE
The preferred way of storing your vehicle for a long
period of time is to leave it attached to a Level 1 or Level
2 charger. The vehicle has a wake-up feature that will
wake the system every 3 weeks and do a maintenance
charge on the 12 Volt battery and also top off the high
voltage battery if necessary.
Anytime you store your vehicle, or keep it out of service
(i.e., vacation) for two weeks or more, run the air
conditioning system at idle for about five minutes in the
fresh air and high blower setting. This will ensure
adequate system lubrication to minimize the possibility
of compressor damage when the air conditioning system
is started again.
310 MAINTAINING YOUR VEHICLE
