Instrument Panel Visual Indicator
Additionally the vehicle is equipped with a visual charge
indicator. The indicator is made up of five lights that are
mounted to the center of the instrument panel.
The charge indicator represents the current state of
charge for the high voltage battery. The charge indicator
lights quickly to identify the battery state of charge while
the vehicle is being charged. Each light represents the
percent of charge that the battery is currently at.
NOTE: In the event of an error in the charging process
the outer two lights will blink.
Number Of Indicator
Lights Illuminated
Percent Of Battery
Charge
1 Light 0 – 20%
2 Lights 21 – 40%
3 Lights 41 – 60%
4 Lights 61 – 80%
5 Lights 81 – 100%
Visual Charge Indicator
32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE
