Fiat DOBLO 2016 - Correct Reading of the Rim Code; Rim Protector Tyres

95 690 kg
99 775 kg
RIM PROTECTOR TYRES
155)
WARNING
155) Do NOT fit hub caps when using
integral caps fixed (with springs) to the
steel rim and aftersales tyres provided with
Rim Protector fig. 228. The use of
unsuitable tyres and hub caps may cause
sudden loss of tyre pressure.
CORRECT READING OF
THE RIM CODE
Example: 6J x 15 ET 43 (see fig.
227)
6 rim width in inches (1).
J rim drop centre outline (side
projection where the tyre bead rests)
(2).
15 rim fitting diameter in inches
(corresponds to the diameter of the
tyre to be mounted) (3 = Ø).
ET 43 wheel camber (distance between
the disc/rim support plane and
the wheel rim centre line).
228
F1A0248
210
TECHNICAL DATA
