Fiat DOBLO 2016 - Third Brake Lights

THIRD BRAKE LIGHTS
To replace the bulb proceed as follows:
for versions with tailgate, undo the
two fixing screws A fig. 161 and
remove the unit;
for versions with wing doors, remove
the rubber caps B fig. 162 and
manoeuvre the holding tabs C, then
remove the unit;
for versions with high roof and swing
doors, remove the pressure-fit plastic
guard A fig. 163 and rubber cap B
fig. 163, using a screwdriver, release
the retaining tags as shown in the figure
and remove the unit;
manoeuvre the appropriate tabs and
remove the bulb holder;
remove the snap-fitted bulb and
replace.
159
F0V0034
160
F0V0525
161
F0V0163
162
F0V0164
163
F0V0231
149
