4
Web Configuration Guide
4.3.1.1
Basic Configuration
Configure
the parameters of the wireless network such as the switch,
network mode, area, band and frequency bandwidth.
1. Select Network in the navigation bar and select Wlan Settings
→Basic in the left link bar to open the basic setting tab of the
wireless access service, as shown in Figure 4.9.
Figure
4.9 Basic Configuration of Wireless Network
2
. Configure the basic parameters of the wireless network. See
Table 4.2 for the parameter description.
3. Click Apply to save and apply the configuration.
T
able 4.2 Basic Parameters of the Wireless Network
Item Description
Radio ON/OFF
Enables or disables the WLAN service. RADIO ON: the
wireless network is enabled; RADIO OFF: the wireless
network is disabled.
Network Mode
The mode supported by the wireless network. The
values include: 802.11b, 802.11g, 802.11b/g, 802.11n
and 802.11b/g/n. The default setting is 802.11b/g/n.
Domain Nation.
72
