7. RS232 DATA OUTPUT MODE
There are 3 data output modes are available
34
. : -
 Mode 1 and Mode 2 are for communication with computer and other
peripherals which accepts and processes continuous data
communication,
 Mode 3 is for transmission to printer or other peripherals which accept
only single or manual data transmission.
7.1 AUTO WEIGHT FORMAT STRING
35
36
Data is transmitted in ASCII code. Data format is listed on below table.
DATA BIT
DESCRIPTION
1~2
MOTION STATUS
US = UNSTABLE
ST = STABLE
3
COMMA SEPARATION
4~5
NET/GROSS
NT = NET WEIGHT
GS = GROSS WEIGHT
6
SIGN (Sign of weight reading)
Positive = space. Negative = minus (-)
7~13
WEIGHT VALUE
7 digits weight value including location of decimal point. If
there is no decimal point, then the first character = space.
14
COMMA SEPARATION
15~16
UNIT
kg = kilogram
lb = pound
17
Cr
18
LF
34
Refer to F18 for more information.
35
When F18 is either set to MODE 1 or Mode 2
36
Overloaded weight will not be sent.
