8. TICKET / RECEIPT PRINTING
If a ticket/receipt printer is used, select Mode 3… normal should be
selected in internal function F18.
8.1 STANDARD PRINT OUTPUT FORMAT
37
38
Standard ticket/receipt printout of various function modes are illustrated
below. Press [PRINT] for manual output or set F17 = ON for automatic
output.
8.1.1 Standard Output Print Format
8.1.1.1 Weighing function
7 lines will be transmitted as below: -
1. Time of print,
2. Date of printing,
3. Transaction sequent number (if this transaction is accumulated to
memory),
4. Net weight,
5. Tare Weight,
6. Gross Weight,
7. Total accumulated net weight (if accumulation function is in effect).
Sample 1
TIME 15:21:00
DATE 14.04.2009
NO. 1 (First transaction added to memory)
NET 500.0kg
TARE 0.0kg
GROSS 500.0kg
TOTAL 500.0kg (Total accumulated net weight)
37
When Normal is selected under MODE 3 of F18
38
This instrument does not support DTR (data of offline detection)
