Fiessler AKAS-3PM - Mechanical data, dimension drawings; AKAS-3 PM;-3 PF transmitter and receiver

Mechanical data, dimension drawings
transmitter and receiver
13
4
4.1
Doku Nr. 1379 Stand 27.1.2017 /Aui
AKAS®-3PM /-3PF
FIESSLER
E L E K T R O N I K
The aluminium housing of both transmitter and receiver are powder coated in RAL 1020 yellow. The optical he-
ad is made of acid-resistant spherically reinforced plastic (polyamide). The support housings are of eloxal
coated aluminium.
With Fiessler tenon blocks
105
173
16,5
55
min 48
max 25
136 mm
13
M 6 x 30
M 8
max 23 mm
76
87,5
30
50
M 6 x 30
50
10
12,2
99
30
32
25
51
34
38
for Fiessler tenon blocks
with 150 mm positioning range: 665 - 680 mm with 190 mm positioning range: 705 - 720mm
bending line
fastening screws
Fig. 13/1
housing type
fastening
dimensions
