Fiessler AKAS-3PM - Range and Holder Specifications

Mechanical data, dimension drawings
Max. Standard-Range / Max. positioning range of the supports / Fiessler Holders
14
max. Standard-Range
between transmitter/receiver unit
8 m
max. Upper tool length
6m
(For longer range please get in
contact with Fiessler Elektronik or
your local dealer).
max. positioning range of the
supports
AKAS®-3...
Standard 150 mm
(190 mm as option)
(On demand, supports with larger
position ranges are available)
Fiessler Holders
4
4.4
Fig. 14/ 1
Upper tool
Matrix
trans-
mitter
receiver
Ram
Support Support
Standard 150mm (190mm as option





























































200 ±10 mm
min
140 mm
167 mm
4 x11 Ø
4xM10
max
155 mm
10
30
50
70
AKAS































drawing, view from the top fig. 14/5




200 ±10 mm
min
140 mm
max
155 mm
10
30
50
70
AKAS






















D
E
CAB
Holder for AKAS®-3...
order code AKAS/AS/U (optional)
swiveling adaptor for Holder AKAS/AS/U
order code AKAS/AS/U/S (optional)
drawing, view from the top fig. 14/3
closed fig. 14/6
open fig. 14/7
front view fig. 14/2
rear view fig. 14/4
max. 8m (between transmitter/receiver)
FIESSLER
E L E K T R O N I K
max. Upper tool length 6m
Doku Nr. 1379 Stand 27.1.2017 /Aui
