BY PASS + CHLORINATOR + PH CONTROL
CHLORINATOR + PH CONTROL
14
15
• Chlorinator consists of a cell and a
chlorinator controller.
• The pH controller consists of a peristaltic
pump, a probe sensor, and an injector.
It is strictly forbidden to store pH
containers inside the tank.
Read the accompanying settings, operating and main-
tenance guide.
• The by-pass consists of a 3-way valve and a branch Tee.
You are advised to seal the pipe entries in order to prevent the
ingress of water into the tank.
• Chlorinator consists of a cell and a chlorinator controller.
• The pH controller
consists of a peristaltic
pump, a probe sensor,
and an injector.
We recommend a covered
inspection pit (not provided)
next to the tank for storing
the container.
TO POOL RETURN
TO HEAT PUMP
